Parts List
Authorized Service Center Stock Inventory
ELE-000-614-FRU Thermostat, VAC High Limit 215*F 1 Ring Terminal 1
ELE-175-188 Thermostat, Control 1/2″ NPT, 17S*F -188*F 2
ELE-800–002 Switch, Fluid Level Brass w/connectors 1
ELE-HLT-322 Thermostat, High Limit VAC 220*F 1
ELE-HLT-425 Thermostat, VAC/High Limit 215*f w/spade connectors 1
ELE-LTC-608 Thermostat, Low Temp Cut-Off 2/Spade Connectors 1
ELX-630-001 Relay, 30A 277 VAC 12VDC Coil 1
FLE-120-100 Filter, Canister General Replacement (Garber) 4
FLX-R12-TRA Filter, Fuel, Racer Spin-On, 10 Micron 4
HDE-700-200 Gasket, Flame Tube outer 1
HDE-700-205 Gasket, Combustion Chamber Tube 4
MSX-300-270 Antifreeze, PG Boiler, 1 Gallon Container (Pink) 6
MSX-300-300 Antifreeze, PG Boiler, 1 Gallon Container (Green) 6
PLX-09P-100 Valve, Tempering 145*F 1
WPX-265-53A Combustion Chamber, DBW 2010 1
WPX-274-313 Electrode Ignition, DBW 2010 4
WPX-298-962 Grommet, Blower Casting, Left, DBW 2010 10
WPX-299-995 Grommet, Blower Casting, Right, DBW 2010 10
WPX-350-516 Clutch Half, 6mm 6
WPX-378-313 Bearing Kit, DBW-2010 1
WPX-412-244 0 -Ring, Blower Casting, DBW 2010 2
WPX-638-78A Sensor, Flame, DWB 2010 1
WPX-886-41A Nozzle, Fuel, 0.35/60* 4
WPX-887-71A Photo disc, DWB 2010 2
Recommended Stocking Inventory
ELE-375-015 Card, Buck Boost 1
ELE-800-006-FRU Kit, Fluid Level Sensor, Fru 1
ELX-375-015 Sensor, flame 1
ELX-375-030 Igniter, Flame 1
ELX-800-005 Switch, Fluid Level Conductive 1
ELX-AMP-005 Circuit, Amp 1
PLE-100-905-FRU Kit, Buehler, 400/450 pump 1
PLX-4A8-18R Valve Repair Kit, Tempering AH 1
WPX-151-157 Gasket Ring, Copper 8
WPX-152-390 Snap Ring, Gear 1
WPX-178-624 Wire, lginition, DBW 2010 2
WPX-225-67A Cast ing, Blower, DBW 2010 1
WPX-287-962 Control Unit, 12VDC, DBW 2010 1
WPX-386-650 Valve Kit, Fuel Solenoid, DBW 2010 1
WPX-425-060 Motor, Combustion Air, 12V, DBW 2010 1
WPX-434-795 Harness, C-Plug, DBW 2010 1
WPX-453-048 Clip, Retaining, Photo Disc 1
WPX-503-03A Pump, Fuel 10 Bar Kit, DBW 2010 1
Recommended Tool Inventory
MSX-907-162 Test, Refractometer 1
WPE-600-190 Gauge Kit, Fuel pressure 1
WPX-310-646 Gauge, Electrode Adjustment 1
WPX-440-280 Control Box, Tester, DBW 2010 1
